Catalina Pony Bottle Tanks with Pro Valve 40 cu. ft Yellow
SKU: AQUTP40 MFR: AC0040YLSSVC48P
Key Features
- Ensure safety on every dive with this Catalina pony bottle tank, your reliable backup air source.
- These aluminum tanks are Nitrox ready, supporting mixes up to 40% oxygen for enriched air diving.
- Choose from multiple sizes of Catalina scuba tanks to suit your specific diving needs and preferences.
- Equipped with a Pro valve, these tanks offer a convertible design for Yoke or DIN regulator setups.
- The Catalina pony bottle's compact size and lightweight design make it ideal for travel and easy handling.
- Rest easy knowing Catalina tanks come with a manufacturer's lifetime limited warranty for peace of mind.
Free Shipping
See Options
1
Need help? Ask our experts.
Overview
Compare
Accessories
Specs
Q&A
About Catalina Pony Bottle Tanks with Pro Valve
FEATURED REVIEWS
Perfect Pony
I use the Aqua Genesis as a pony bottle. I chose the 30 cubic ft size because carries enough air to get me to the surface in any of the situations I am likely to encounter. Also it is big enough to be used as a stage bottle.
good item [...]
air for Dry suit
Explanation on the Back Pressure Relief Feature
In course of using a scuba valve, there are times where excess air may have accumulated behind the face o-ring during normal use. When this air is not vented properly from the o-ring groove it can cause the o-ring to dislodge during regulator dismounting.
Sherwood valves feature an intentional stamping mark in the machined inner ring of the o-ring gland. This mark prevents the metal ring from sealing against the 1st Stage regulator and trapping pressurized gas in the o-ring groove. If this gas is not properly vented, it can force the o-ring to dislodge when the 1st stage is removed from the valve. The stamping mark creates a path to vent any trapped gas before the 1st stage is removed.
A pony bottle is a smaller tank, which is carried in addition to the main tank. It possesses its own regulator with first and second stage and sometimes a separate pressure gauge. It will is mounted either at ones side or in front of the body or fixed to the main tank. A pony bottle scuba tank is the only true redundant breathing mechanism you can completely rely on.
Depending on the type of diving you plan on doing will determine what capacity the redundant air supply needs to be. Leisure Pro offers five different size bottles to meet every divers requirements. If used for sport diving there are three choices 6, 13 and 19 cu ft cylinders. If deep or deep technical diving or wreck penetration or cave diving there are the 30 and 40 cu ft cylinders available.
The Pro Valve is one of the highest flow cylinder valves available today and is also a convertible valve. Whether you dive Yoke or DIN regulators this valve will work for both. Valve has easily removed 200 bar (3000 psi) DIN insert to convert the valve for use with DIN regulators. Valve has a heavy duty deign with a smooth operating mechanism and multi-ported burst disc plug for added safety.
Aluminum cylinders unlike steel cylinders don't rust, they oxidize. The oxidization of aluminum forms a protective coat that hinders the continuation of corrosion making aluminum cylinders less likely to be condemned due to excessive corrosion. When shipped the tanks valves will be removed and the tank will require re-inspection before being filled. The available cylinders have the following physical specifications:
Diameters:
6 cu. ft: 3.2" (8.13cm)
13 and 19 cu. ft: 4.38" (11.13cm)
30 and 40 cu. ft: 5.25 (13.34cm)
Height:
6 cu. ft: 10.8" (27.4cm)
13 cu. ft: 12.8" (32.5cm)
19 cu. ft: 17.40" (44.2cm)
30 cu. ft: 19.98" (50.75cm)
40 cu. ft: 24.85" (63.1cm)
Weight:
6 cu. ft: 2.6 lbs (1.18kg)
13 cu. ft: 5.7 lbs (2.59kg)
19 cu. ft: 7.8 lbs (3.5kg)
30 cu. ft: 13.7 lbs (6.2kg)
40 cu. ft: 15.9 lbs (7.2kg)
Buoyancy (Full):
6 cu. ft: -1.5 lbs (-680.4g)
13 cu. ft: -1.7 lbs (771g)
19 cu. ft: -1.3 lbs (589.7g)
30 cu. ft: -2.4 lbs (1.1kg)
40 cu. ft: -2.6 lbs (1.2kg)
Note:All Catalina cylinders are nitrox ready and meet certificated specifications of the US Department of Transportation (DOT) with DOT-3AL specification and Transport Canada Safety and Security (TC) with TC-3ALM specifications. Purchasers should check with other country requirements to know if the cylinders are certified for use in that country.
Catalina Pony Bottle Tanks with Pro Valve Features
- Pony Bottle Tanks with Pro Valve:
- Nitrox Ready Up to 40%
- Five Sizes to Choose
- Most Reliable Redundant Air Source
- Cylinder: Catalina Pony Bottles:
- Thread Size: 0.750-14 NPSM
- Aluminum Alloy Design
- Won't Rust Like Steel Cylinders
- Best for Sport Divers: 6, 13 & 19 cu. ft. Cylinders
- Great for Deep & Deep Technical Diving: 30 & 40 cu. ft. Cylinders
- Service Pressure: 3000 psi (200 bar)
- Note:
All Catalina Cylinders Meet Certificated Specifications of US Department of Transportation (DOT) w/DOT-3AL
Meet Specification of Transport Canada Safety & Security (TC) w/TC-3ALM - Physical Specifications:
- Buoyancy (Full):
6 cu. ft: -1.5 lbs (-680.4g)
13 cu. ft: -1.7 lbs (771g)
19 cu. ft: -1.3 lbs (589.7g)
30 cu. ft: -2.4 lbs (1.1kg)
40 cu. ft: -2.6 lbs (1.2kg) - Diameters:
6 cu. ft: 3.2" (8.13cm)
13 & 19 cu. ft: 4.38" (11.13cm)
30 & 40 cu. ft: 5.25 (13.34cm) - Height:
6 cu. ft: 10.8" (27.4cm)
13 cu. ft: 12.8" (32.5cm)
19 cu. ft: 17.40" (44.2cm)
30 cu. ft: 19.98" (50.75cm)
40 cu. ft: 24.85" (63.1cm) - Weight:
6 cu. ft: 2.6 lbs (1.18kg)
13 cu. ft: 5.7 lbs (2.59kg)
19 cu. ft: 7.8 lbs (3.5kg)
30 cu. ft: 13.7 lbs (6.2kg)
40 cu. ft: 15.9 lbs (7.2kg) - Buoyancy (Full):
6 cu. ft: -1.5 lbs (-680.4g)
13 cu. ft: -1.7 lbs (771g)
19 cu. ft: -1.3 lbs (589.7g)
30 cu. ft: -2.4 lbs (1.1kg)
40 cu. ft: -2.6 lbs (1.2kg) - Valve: Pro Valve
- Convertible K-Valve
- Yoke or DIN
- Heavy Duty Design
- Smooth Operating Valve Mechanism
- Chrome Plated Marine Brass
- Multi-Ported Burst Plug Assembly
- High Flow Capacity Valve
Warranty Information
This product has a limited lifetime warranty.
